MANUAL FOR SOVIET. MOSIN-NAGANT. MODELS OF. - -- /30 -- -- RIFLES, CARBINES &. SNIPER RIFLES. ORDI M39, & M Important! Read this manual first! The Russian Model Mosin-Nagant bolt-action rifle was among the earliest military firearms designed to. The Mosin‒Nagant (Russian: Винтовка Мосина, ISO 9: Vintovka Mosina) is a As a front-line rifle, the Mosin–Nagant served in various forms from until.
|Language:||English, French, Portuguese|
|Genre:||Children & Youth|
|ePub File Size:||16.73 MB|
|PDF File Size:||17.55 MB|
|Distribution:||Free* [*Sign up for free]|
OPERATING INSTRUCTIONS. Rifle M Dragoon rifle .. The Mosin- Nagant rifle was adopted in by Imperial Russia. The action of the rifle was. Manual for soviet Mosin-Nagant. Manual for rifles Size Report. DOWNLOAD PDF LRFD Manual, Manual For Engineered Wood Construction. Read more. Download as PDF or read online from Scribd MANUAL FOR SOVIET MOSIN- NAGANT MANUAL FOR RIFLES & CARBINES ORDNANCE CORPS MAY .
To strip the bolt, fig. Pull out on the cocking piece against spring pressure and rotate it counter- clockwise, allowing it to go forward once it has been rotated. Next, grasp the bolt head by the locking lugs and pull it forward until it stops.
Then rotate the bolt head counter-clockwise slightly farther than a quarter turn. This allows the bolt head to be pulled off the bolt body. Now the bolt guide which extends the entire length of the bolt can be pulled to the front and off the bolt body. To remove the firing pin, fig. The firing pin remains under spring pressure, so when the pin is unscrewed, care must be taken to prevent parts from springing loose when the firing pin is removed.
Removal of the firing pin allows the striker spring to be removed, and it allows the cocking piece to fall free of the bolt. To reassemble, fig.
Note that care needs to be taken not to damage threads when depressing the main spring and starting to engage the threads at the rear of the firing pin and in the cocking piece. Make certain marks on the rear end of the firing pin and on the cocking piece match when reassembling fig.
How to make a Prop Mosin Nagant M Rifle
Next, squeeze the floorplate fig. This opens the hinge at the end of the floorplate, allowing it to be pulled free of the magazine housing.
To remove the barreled action from the stock, take off the two barrel bands by depressing the spring keepers which hold the bands to the rifle. Next, lift off the handguard and then invert the rifle and remove the action bolts at either end. Reassembly is the reverse procedure.
There should be no particular tricks needed to take the rifle apart and to reassemble it. When not in use, it is wise to store these rifles in a cool, dry place. Exposed metal surfaces should be coated with some form of oil or grease to prevent rust. To clean the Mosin-Nagant rifle, remove the bolt from the action and assure that the rifle is completely unloaded. First it is necessary to clean the bore. To accomplish this, it is necessary to have a cleaning rod long enough to go through the full length of the barrel and to have cloth patches these can be made from cotton or cotton-blend cloth and should be large enough to rub against the bore of the rifle as they are pushed by the cleaning rod, but not so large as to cause severe resistance when used.
Chronologically, a patch soaked with powder solvent should be used first. Any of the commercially available solvents will work well if non-corrosive ammunition has been used. If the ammunition used has corrosive priming, it is necessary to neutralize the salts which are byproducts of firing. This can be done with solvents designed specifically for corrosive priming, or liberal use of soap or detergent and water will work.
Remove the sling by unbuckling the dog collars and removing them from the sling slots. Unscrew the cleaning rod counterclockwise Depress the barrel band retaining springs and slide the barrel bands forward.
Slide both barrel bands forward past the end of the stock and remove the handguard.
The barrel bands will not come off the barrel at this time due to the front sight. Other models may differ in this.
Hold the trigger back and pull the bolt straight to the rear. Decock the bolt by turning the cocking knob 90 degrees counterclockwise and pull the bolt head and connector bar forward. Rotate the bolt head 90 degrees clockwise and pull it off the connector bar.
Using the large notch on the bolt tool or the connector bar as a wrench, grasp the firing pin between the fingers and unscrew it counterclockwise. Be careful to grasp it firmly as the spring is under pressure.
Remove the magazine tang screw. Remove the receiver tang screw. Remove the magazine assembly and receiver assembly from the stock. Some Mosins, especially Finnish, but Russian and Soviet also, have shims at the tang and recoil lug. When removing the action from the stock be careful not to lose the shims and note their location. The trigger pin is held in place only by the stock and if it is loose can fall out upon removal of the action. Depress the floorplate latch and pull the floorplate away from the magazine body.
Compress the follower assembly and pull it straight down from the magazine body. This completes partial disassembly for routine cleaning and maintenance.
For detailed disassembly, including the magazine and bolt assemblies, continue below. Unscrew the butt plate. Drift out the front and rear barrel band springs from the opposite side of the stock with a small blunt nail or punch.
Shop by category
A hole for this purpose should be visible. These springs are delicate and can be easily broken if pulled out by the leaf. Some Mosins, especially Finnish, but Russian and Soviet also, have shims at the tang and recoil lug.
When removing the action from the stock be careful not to lose the shims and note their location. The trigger pin is held in place only by the stock and if it is loose can fall out upon removal of the action.
Depress the floorplate latch and pull the floorplate away from the magazine body. Compress the follower assembly and pull it straight down from the magazine body.
This completes partial disassembly for routine cleaning and maintenance. For detailed disassembly, including the magazine and bolt assemblies, continue below. Unscrew the butt plate. Drift out the front and rear barrel band springs from the opposite side of the stock with a small blunt nail or punch.
Just another WordPress site
A hole for this purpose should be visible. These springs are delicate and can be easily broken if pulled out by the leaf. Remove the nose cap screw and slide the nose cap forward off the end of the stock. The nose cap screw will thread into the top of the cleaning rod retaining nut and can aid in pulling it out of the stock.
Note: Removal of the retaining nut is seldom necessary or worth risking damage to the nose cap screw. Turn the stock recoil bolt nut counterclockwise with retaining ring pliers or another suitable tool. Carefully drive the recoil bolt out of the stock with a punch. Note: Removal of the recoil bolt is seldom necessary and there is a risk of damaging it.
Drift out the follower pin and follower carrier pin. The follower carrier spring is screwed to the floorplate. The follower spring can be removed from the follower carrier by lifting up and back. Drift out the rear sight leaf pin and lift the rear sight leaf spring out of the rear sight base.
Remove the rear sight slide from the leaf and pull the buttons and their springs out each side. Drift out the rear sight base pins and drift the rear sight base forward off of the dovetail.
Drift the front sight off of it's base.The rear sight slide is removed from the rear of the slide and can be done with the slide on or off of the rear sight base. Both rifles and carbines using the design by Imperial Russian Army Colonel Serge Moisin and Belgian arms maker Emile Nagant have been manufactured in China, Finland, France, North Korea, Russia, Switzerland and the United States, and remained in military service at various places around the world for more than 60 years.
Below are the exceptions to the above instructions for all other commonly encountered models of Mosins. Repeat on the other side and remove the slide. The Dragoon rifle M is believed to be obsolete, but it may be found in limited quantity in satellite armies.
